Hardware

ESPresense supports various LED and GPIO sensor configurations for enhanced functionality and visual feedback. These settings are accessible from the Hardware page in the device web UI.

LEDs

Configure up to 3 addressable LEDs for visual feedback and status indication.

LED Configuration

For each LED (LED 1, LED 2, LED 3), you can configure:

• LED Type - Select the type of addressable LED strip (WS2812, SK6812, etc.)
• Pin (-1 to disable) - GPIO pin number for the LED data line, or -1 to disable
• Count (only applies to Addressable LEDs) - Number of LEDs in the strip
• LED Control - Control mode for the LED behavior

GPIO Sensors

Configure motion sensors, switches, and buttons connected to GPIO pins.

PIR (Passive Infrared)

Motion detection using PIR sensors:

• PIR motion pin type - Input type configuration for the PIR sensor
• PIR motion pin (-1 for disable) - GPIO pin number for PIR sensor, or -1 to disable
• PIR motion timeout (in seconds) - How long to keep motion state active after detection

Radar

Motion detection using radar sensors:

• Radar motion pin type - Input type configuration for the radar sensor
• Radar motion pin (-1 for disable) - GPIO pin number for radar sensor, or -1 to disable
• Radar motion timeout (in seconds) - How long to keep motion state active after detection

LD2410(b/c)

These are 24GHz radar motion sensors (B & C variants have integrated Bluetooth). These devices have a UART serial port which is unused by ESPresense; we use a single pin to indicate motion/static presence.

To use these with ESPresense, connect Power and Ground, and wire the ‘Occupied’ pin to a GPIO. Configure it with Radar motion pin type as needed (usually Pullup or Input depending on wiring).

Pin Types

For GPIO sensors (PIR, Radar, Switches, Buttons), the following pin types are available to match your hardware wiring:

• Pullup / Pullup Inverted
• Pulldown / Pulldown Inverted
• Floating / Floating Inverted

Switches

Configure up to 2 switch inputs:

Switch One / Switch Two

• Switch pin type - Input type configuration for the switch
• Switch pin (-1 for disable) - GPIO pin number for the switch, or -1 to disable
• Switch timeout (in seconds) - Debounce timeout for switch activation

Buttons

Configure up to 2 button inputs:

Button One / Button Two

• Button pin type - Input type configuration for the button
• Button pin (-1 for disable) - GPIO pin number for the button, or -1 to disable
• Button timeout (in seconds) - Debounce timeout for button presses

Temperature Sensors

Configure various temperature and humidity sensors.

DHT11 / DHT22

• DHT11/DHT22 sensor pin - GPIO pin number for the sensor
• DHT temperature offset - Calibration offset for temperature readings

DS18B20

• DS18B20 sensor pin - GPIO pin number for the One-Wire bus
• DS18B20 temperature offset - Calibration offset for temperature readings

I2C Settings

Configure up to 2 I2C buses.

Bus 1 / Bus 2

• SDA pin - GPIO pin for Serial Data
• SCL pin - GPIO pin for Serial Clock
• Debug I2C addresses - Scans the bus and logs found addresses to serial console

I2C Sensors

Configure various I2C environmental and light sensors.

General Sensors

Supported sensors: AHTX0, BH1750, BME280, BMP085, BMP280, TSL2561, SGP30, SCD4x.

• I2C Bus - Select which I2C bus (1 or 2) the sensor is connected to.
• I2C address - Specific hex address (e.g., 0x76).
• Gain (TSL2561 only) - Luminous gain setting (auto, 1x, 16x).

SHT Series

Supported sensors: SHT3x, SHT4x, SHT85.

• I2C Bus (-1 to disable) - Select bus or -1 to disable.

Weight Sensor (HX711)

Configure a load cell amplifier.

• HX711 SCK (Clock) pin - GPIO pin for the clock line.
• HX711 DOUT (Data) pin - GPIO pin for the data line.

Tips

• Set pin values to -1 to disable any unused sensors or LEDs
• Ensure GPIO pins don’t conflict with other hardware functions
• Addressable LEDs require proper power supply for multiple LEDs
• Use appropriate timeout values to avoid false triggers on motion sensors
